คุณสมบัติ
– ใช้ไฟเลี้ยง 12V
– มีจอแสดงผล
– สามารถตั้งเวลาการทำงานได้
– ขนาด 64.2mm x 34.8mm x 18.5mm.
– Relay ควบคุมไฟ 220V
Description
– New upgrades to simplifyto meet customer needs.
– Increase the supply anti-reversefunction.
– The use of opto isolated input and outputenhanced anti-jamming capabilit
– consumption.
– Set parameter after power for ever memories.
– Signal terminal voltage signal can be maintained for a longtime.
– to ensure stabilityindustrial grade boardclass PLC.
Product parameters
– Size:64.2mm*34.8mm*18.5mm.
– Relay Specifications:AC 220V 10A or DC 30V 10A.
– Quiescent Current:20mAOperating Current:50mA.
– Working voltage:10~16V (if other ranges can be customized).
– Signal voltage:4V~20V (if other ranges can be customized).
– life:about100000timesWorking temperature:-40~85’C.
